We can offers a great variety of small-diameter, single-wall and electric-welded tube. With excellent workability, fatigue strength, precision and cleanliness, electric-welded tube provides high quality at a low cost.
Related Certified Spec.
GBT 24187-2009: Chinese Standards
SAE J526: Society of Automotive Engineers
ASTM-A254 : American Society for Testing Materials
MS191-21 : HYUNDAI & KIA Motors Standards
JASO M 101 : Japanese Automotive Standards
● Economic
● Smooth outer surface
● Maintaining inner cleanliness to the max. of 0.1948g/m2
● Durability with air-tightness against vibration and impact
● Diverse processing available
● Tensile Strength:≥290MPa
● Yield Strength:≥200MPa
● Elongation:≥40%
● Flaring TestFlaring:≥25%
| O.D(mm) | THICKNESS(mm) | UNIT WEIGHT(g/m) | WORK PRESSURE(kg/㎡) |
| 4.00 | 0.5 | 43.16 | 350 |
| 4.00 | 0.7 | 56.97 | 350 |
| 4.76 | 0.6 | 61.56 | 350 |
| 4.76 | 0.7 | 70.00 | 350 |
| 6.00 | 0.7 | 91.49 | 350 |
| 6.00 | 1.0 | 123.31 | 350 |
| 6.35 | 0.7 | 97.54 | 350 |
| 8.00 | 0.7 | 126.02 | 250 |
| 8.00 | 1.0 | 172.63 | 250 |
| 9.52 | 1.7 | 152.26 | 250 |
| 9.52 | 1.0 | 210.12 | 250 |
| 10.0 | 1.7 | 160.55 | 250 |
| 10.0 | 1.0 | 221.95 | 250 |
| 12.0 | 0.7 | 195.07 | 250 |
| 12.0 | 1.0 | 271.28 | 250 |
| 12.7 | 0.7 | 207.16 | 250 |
| 12.7 | 1.0 | 288.54 | 250 |
